Materials Specification

Material Type Allen FR 3030 PC/ABS Lustran 552 ABS UL-HB Boltaron 6540 R85/21 R63 R59
Data Sheet Download Download Download Download Download Download
RoHS Download Download Download Download
Yellowcard Number Download Download Download
Flammability Rating UL94V-0 UL94HB MVSS 302, UL94V-0 MVSS 302 MVSS 302, UL94V-0, UL94-5V
Foam Core No No No No No No
Composite Material Yes No No Yes No No
Static Dissipative No No No No No No
Specific Gravity 1.18 1.32 1.05 1.22 1.18
Heat Deflection @264 psi) 165°F 200°F 174°F 175°F
Tensile Strength (psi) 6300 4800 5000 4700
Flexural Strength (psi) 405,000 75 10000 9000 5700 7700
@-20F (ft-lb/in notch) 3 N/A 1.8
@-40F (ft-lb/in notch) N/A N/A N/A
@72F (ft-lb/in notch) 14 8 3 7
Light Transmission N/A N/A N/A
Refractive Index N/A N/A N/A
